Standard Motor Products TPMS Sensor TPM23A

Standard Motor Products TPM23A is a banded 315 MHz TPMS sensor listed for the 2007 Ford F150, OE style and ID clone-able, with no programming needed.

Part number: TPM23A
Condition: New
Our SKU: TPM23A

Add your vehicle above to check this part against it.

$54.43

In stock

Shipping options and cost shown at checkout
Returns accepted on unused parts, see our returns policy
Unsure about fit? Send your VIN before you order

Vehicle fitment

Year	Make	Model	Trim, body and engine
2007	Ford	F150	All

Rows are what the manufacturer lists for this part. If your trim or engine is missing, contact us with your VIN before ordering.

About this part

The TPM23A is a light duty, banded tire pressure sensor. Unlike a valve stem mounted sensor, a banded design is held to the wheel by a strap around the drop center. It runs at 315 MHz and is OE style, and its ID can be cloned from your old sensor. The note says no programming is required: you install the sensor and follow the factory relearn procedure.

Fitment notes

The catalog lists the 2007 Ford F150. Check that your truck uses banded sensors rather than valve stem sensors, since the two are not interchangeable. Confirm in the fitment table or send your VIN before ordering.

Specifications and features

Banded sensor design
Frequency: 315 MHz
OE style, ID clone-able
Light duty
No programming required

Installation notes

The tire must be removed from the wheel to fit a banded sensor, and the band must be tight and positioned correctly. After installation, follow the factory relearn procedure so the system reads the new sensor.
